Operation Temperature : -20℃ ~ 80℃
Storage Temperature : -20℃ ~ 100℃
Additional Heat-sink equipment is recommended when operation temperature is higher than 60℃.
|
Part Number
|
Chip
|
Lens Color
|
Forward voltage
Vf(V) |
Mcd@Forward current If(mA)
=20mA
|
||||
|
Material
|
Color
|
λD(nm)
|
Min
|
Max
|
Min
|
Typ
|
||
|
4.8W8HDB
|
InGaN
|
White
|
2700-10000K
|
Water Clear
|
3.0
|
3.7
|
1500
|
2800
|
|
4.8B8HDB
|
InGaN
|
Blue
|
450-475
|
3.0
|
3.7
|
150
|
300
|
|
|
4.8G8HDB
|
InGaN
|
Green
|
500-540
|
2.7
|
3.7
|
700
|
1500
|
|
|
4.8R8HDB
|
AlGalnP
|
Red
|
620-660
|
1.8
|
2.5
|
500
|
1000
|
|
|
4.8Y8HDB
|
AlGalnP
|
Yellow
|
580-595
|
1.8
|
2.5
|
400
|
900
|
|
Note:
1) Above parameter is under condition of 120 degree.
2) Low power dip LED with constant current operation: 20mA.
2) With flange.
3) Viewing angle:120 degree.
4) Application in high power flashlight, LED arrays,LED display, decoration and so on(001)
